Máquina automática de estampado en caliente llano

Payment Type:
L/C,T/T,D/P,Western Union
Incoterm:
FOB,CIF,EXW,FCA,CPT
Min. Order:
1 Set/Sets
Delivery Time:
7 Days
Transportation:
Ocean
Port:
SHENZHEN,GUNGAZHOU,HONGKONG
  • DDescripción
Overview
Product Attributes

ModeloH-TC1015R10

MarcaKC

Supply Ability & Additional Informations

PaqueteCaja de madera

productividad100 Sets/month

transporteOcean

Lugar de origenDongguan

Capacidad de suministro100 Sets/month

Certificados CE

HafenSHENZHEN,GUNGAZHOU,HONGKONG

Tipo de PagoL/C,T/T,D/P,Western Union

IncotermFOB,CIF,EXW,FCA,CPT

Plazo de entrega7 días

Embalaje y entrega
Unidades de venta:
Set/Sets
Tipo de paquete:
Caja de madera

Máquina de estampación en caliente neumática con mesa giratoria // Uso y caracteres

085

  • Gilding - paper, leather, wood, plastic,
  • Baked - wood products, baked painting, gift box packaging;
  • Embossing - paper, leather, cloth.
  • Flat-object stamping machine with large-pressure, Suitable for stamping on invitation letter, card. Leather, wooden gift, Paper package, Plastics film, Electron products;
  • Manual. Automatic feed foil, automatic temperature controlling ensures stamping quality.
  • Because of large pressure, It is suitable for gilding and baking Impression on leather, paper, wooden materials.
  • Pneumatic drive, pressure large.

Application fields

  • Paper Gilding, Leather Impression, Wood ware Baking
  • Paper Concave-convex embossing, Cloth hot stamping,
  • Plastics Bronzing
  • Mobile screen, Household appliances Panel , Thick paper card, PVC board Etc. large dimension Flat substrate stamping and Bronzing.
  • Woodiness objects baking-burns and Impress;
  • Leather bronzing and Molding;
  • Paper products concavo indentation.
  • Graduated disc of clock bronzing.

Pneumatic hot stamping Machine //Parameter


H-TC1010R10

  • Hot plate area:100× 100 mm
  • Working table area: R500mm
  • Max printing pressure:1,000-1500 Kg
  • Up and down distance:100mm
  • Heat wattage:2500W
  • Foil in feed: Motor Drive
  • Temperature adjustment:0-300oC .


H-TC1015R10

  • Hot plate area:100 × 150 mm
  • Working table area: R500mm
  • Max printing pressure:1000-1500 Kg
  • Up and down distance:100mm
  • Heat wattage:2500W
  • Foil in feed: Motor Drive
  • Temperature adjustment:0-300oC


Works supply:110V-220VPower supply;5-7Bar compress air

Package size: . 0.770×0.820×1.550mm

Gross weight: 220kg

CBM: 1.0145


H.S.Code: 8443198000


Certificate: CE


Pneumatic hot stamping machine  with servo working table //Advantage

  • Table can be pulled into and pulled out the pick and place of convenience products;
  • Table can be up and down, around, before and after the precision adjustment, to facilitate the adjustment of the precise location of the gilt;
  • Table lifting screw adjustment, simple and convenient;
  • Relays for process control, stable operation, easy maintenance;
  • The use of advanced temperature control system, the temperature can be set freely, high precision temperature control, with automatic temperature control;
  • leveraged cylinder pressure, the pressure is uniform and strong;
  • The basic parameters of the hot stamping process; temperature, pressure, hot pressure, the rolls of time in accordance with the process requirements of the flexible adjustment;
  • Motor to control the delivery of the gold foil paper, resin length can be flexibly adjusted according to the size of the stamping area;
  • Using high strength steel, gilt plate and table, has a very high flatness;
  • Heating tube for heating, heat supply is stable, easy to replace
